前言

本文将对vue组件如何解析以及渲染做一个讲解。

我们可以通过Vue.component注册全局组件,之后可以在模板中进行使用

<div id="app">
  <my-button></my-button>
</div>
<script>
 Vue.component("my-button", {
    template: "<button> 按钮组件</button>",
   });
let vm = new Vue({
	el:'#app'
});
</script>

全局组件解析原理

为了保证组件的隔离,每个组件通过extend方法产生一个新的类,去继承父类。并把用户通过Vue.component方法传入的 opts 合并到 vue.options.components,再vue初始化时合并Vue.options.components 和 vm.$options.components 。

1.Vue.component 方法

Vue.options._base = Vue; //可以通过\_base 找到 vue
Vue.options.components = {};

Vue.component = function (id, definition) {
  //每个组件产生一个新的类去继承父亲
  definition = this.options._base.extend(definition);

  console.log("1.给组件创造一个构造函数,基于Vue", definition);

  this.options.components[id] = definition;
 };

2.Vue.extend 方法

extend 方法就是产生一个继承于 Vue 的类,并且他身上应该有父类的所有功能。

import {mergeOptions} from '../util/index'
Vue.extend = function (definition) {
  const Vue = this;
  const Sub = function VueComponent(options) {
   this._init(options);
  };
  Sub.prototype = Object.create(Vue.prototype);
  Sub.prototype.constructor = Sub;
  Sub.options = mergeOptions(Vue.options, definition);
  return Sub;
 };

3.属性合并

合并Vue.options 和 Vue.component(definition)传入的 definition

strats.components = function (parentVal, childVal) {
 let options = Object.create(parentVal);
 if (childVal) {
  for (let key in childVal) {
   options[key] = childVal[key];
  }
 }
 return options;
};

4.初始化合并

合并Vue.options.components 和 vm.$options.components

 Vue.prototype._init = function (options) {
  const vm = this;
 ++ vm.$options = mergeOptions(vm.constructor.options, options);
  //...
  initState(vm);
  if (vm.$options.el) {
   //将数据挂载到这个模版上
   vm.$mount(vm.$options.el);
  }
 };

好哒,到这里我们就实现了全局组件的解析。

下面我们再来康康组件如何渲染的吧?

组件的渲染原理

在创建虚拟节点时我们要通过isReservedTag 判断当前这个标签是否是组件,普通标签的虚拟节点和组件的虚拟节点有所不同,如果 tag 是组件 应该渲染一个组件的 vnode。

export function isReservedTag(str) {
 let reservedTag = "a,div,span,p,img,button,ul,li";
 return reservedTag.includes(str);
}

1.创建组件虚拟节点

createComponent 创建组件的虚拟节点,通过data上有无hook来区分是否为组件

export function createElement(vm, tag, data = {}, ...children) {
  // 如果tag是组件 应该渲染一个组件的vnode
  if (isReservedTag(tag)) {
    return vnode(vm, tag, data, data.key, children, undefined);
  } else {
    const Ctor = vm.$options.components[tag]
    return createComponent(vm, tag, data, data.key, children, Ctor);
  }
}
// 创建组件的虚拟节点, 为了区分组件和元素 data.hook
function createComponent(vm, tag, data, key, children, Ctor) {
  // 组件的构造函数
  if(isObject(Ctor)){
    Ctor = vm.$options._base.extend(Ctor); // Vue.extend
  }
  data.hook = { // 等会渲染组件时 需要调用此初始化方法
    init(vnode){
      let vm = vnode.componentInstance = new Ctor({_isComponent:true}); // new Sub 会用此选项和组件的配置进行合并
      vm.$mount(); // 组件挂载完成后 会在 vnode.componentInstance.$el
    }
  }
  return vnode(vm,`vue-component-${tag}`,data,key,undefined,undefined,{Ctor,children})
}

2.创建组件的真实节点

typeof tag === “string”,有可能是组件的虚拟节点,则调用createComponent。

export function patch(oldVnode,vnode){
  // 1.判断是更新还是要渲染
  if(!oldVnode){
    return createElm(vnode);
  }else{
    // ...
  }
}

function createElm(vnode) {
 let { tag, data, children, text, vm } = vnode;
 if (typeof tag === "string") {
  if (createComponent(vnode)) {
   //返回组件对应的真实节点
   return vnode.componentInstance.$el;
  }
  vnode.el = document.createElement(tag); // 虚拟节点会有一个el属性,对应真实节点
  children.forEach((child) => {
   vnode.el.appendChild(createElm(child));
  });
 } else {
  vnode.el = document.createTextNode(text);
 }
 return vnode.el;
}

createComponent 通过 data上是否有hook.init方法,判断是否组件虚拟节点

是的话则调用组件上 data.hook.init

创建组件实例,并赋值给vnode.componentInstance

vnode.componentInstance 有值说明对应组件的真实 dom 已经生成

function createComponent(vnode) {
  let i = vnode.data;
  if((i = i.hook) && (i = i.init)){
    i(vnode);
  }
  if(vnode.componentInstance){
    return true;
  }
}

调用init方法,创造组件的实例并该进行挂载

data.hook = {
  init(vnode){
    let child = vnode.componentInstance = new Ctor({});
    child.$mount(); // 组件的挂载
  }
}

小结

vue组件是如何解析及渲染的?

对组件进行 new 组件().$mount() => vm.$el

将组件的$el 插入到父容器中 (父组件)

就完成啦~
